PORTAPACCO SPECIFICO - SPECIFIC HOLDER - PORTE-PAQUET SPÉCIFIQUE - SPEZIFISCHER TRÄGER - PORTA-EQUIPAJE ESPECÍFICO
N°
Descrizione
Supporto - Support - Support
1
Halterung - Soporte
Supporto - Support - Support
2
Halterung - Soporte
Supporto - Support - Support
3
Halterung - Soporte
Maniglie - Handles
4
Poignées - Handgriffe
Manijas
Piastra - Plate
5
Platine - Platte
Parrilla
Protezione Adesiva - Adhesive Protection
6
Protection Adhesive - Schutzkleber
Protección Adhesiva
Vite - Screw
7
Vis - Schraube
Tornillo
Vite - Screw
8
Vis - Schraube
Tornillo
Vite - Screw
9
Vis - Schraube
Tornillo
Vite - Screw
10
Vis - Schraube
Tornillo
Vite - Screw
11
Vis - Schraube
Tornillo
Rondella - Washer
12
Rondelle - Scheibe
Arandela
Rondella - Washer
13
Rondelle - Scheibe
Arandela
Rondella - Washer
14
Rondelle - Scheibe
Arandela
Distanziale - Spacer
15
Entretoise - Distanzstueck
Distanciador
©Copyright 2/08/2012 AR-Rev00
SR5604M - KR5604M
PIAGGIO
X10
Caratteristiche
-
TEF M8x30
TCEI M6x25
TCEI M8x25
TBEI M8x35
TBEI M8x25
Ø6
Ø6x18
Ø8x14
Ø20x10 foro 8.5 mm
ISTRUZIONI DI MONTAGGIO - MOUNTING INSTRUCTIONS
INSTRUCTIONS DE MONTAGE - BAUANLEITUNG - INSTRUCCIONES
125-350-500cc (2012)
Codice
GL2197
Z2092
M5M
V447
DE MONTAJE
Quantità
2 (Dx;Sx)
2 (Dx;Sx)
2 (Dx;Sx)
2 (Dx;Sx)
1
2 (Dx;Sx)
2
4
2
4
2
4
4
6
2
1/4
