Wireless-G ADSL Gateway with SpeedBooster
Chapter 3: Getting to Know the Wireless-G ADSL Gateway with
SpeedBooster

Ports and Reset Button on Side Panel

The Gateway's ports and Reset button are located on a side panel.

Figure 3-1: Ports and Reset Button on Side Panel

Line The Line port connects to the ADSL line.
Ethernet (1-4) The Ethernet ports connect to your computers and other network devices.
Reset Button There are two ways to reset the Gateway's factory defaults. Either press the Reset Button,
for approximately five seconds, or restore the defaults from the Factory Defaults screen of
the Administration tab in the Gateway's Web-based Utility.
Power The Power port is where you will connect the power adapter.

Chapter 3: Getting to Know the Wireless-G ADSL Gateway with SpeedBooster

Ports and Reset Button on Side Panel
IMPORTANT: Resetting the Gateway to factory
defaults will erase all of your settings
(including Internet connection, wireless, and
other settings) and replace them with the
factory defaults. Do not reset the Gateway if
you want to retain these settings.
6
