7. CLEANING AND MAINTENANCE ......................12 8. TECHNICAL SPECIFICATIONS......................... 12 Das neueste Update dieser Bedienungsanleitung finden Sie im Internet unter: You can find the latest update of this user manual in the Internet under: www.omnitronic.com 2/12 00031457.DOC, Version 1.1 Downloaded from www.Manualslib.com...
- sich die letzte Version der Anleitung im Internet herunter laden 1. EINFÜHRUNG Wir freuen uns, dass Sie sich für das OMNITRONIC Empfangsmodul RM-105 entschieden haben. Wenn Sie nachfolgende Hinweise beachten, sind wir sicher, dass Sie lange Zeit Freude an Ihrem Kauf haben werden.
2. SICHERHEITSHINWEISE Dieses Gerät hat das Werk in sicherheitstechnisch einwandfreiem Zustand verlassen. Um diesen Zustand zu erhalten und einen gefahrlosen Betrieb sicherzustellen, muss der Anwender unbedingt die Sicherheits- hinweise und die Warnvermerke beachten, die in dieser Gebrauchsanweisung enthalten sind. Unbedingt lesen: Bei Schäden, die durch Nichtbeachtung dieser Bedienungsanleitung verursacht werden, erlischt der Garantieanspruch.
4. GERÄTEÜBERSICHT SET-Taste LCD-Anzeige Zur Aktivierung des Einstellmodus für die Wahl des Zeigt den Übertragungskanal oder die Funkfrequenz an. Empfangskanals und zum Bestätigen. Diversity-Anzeige A/B P/Q-Tasten Signalisiert über die rote bzw. grüne LED, welche der Zur Kanalwahl. Um das Display auf Anzeige der zwei Empfangsantennen [A/B] zurzeit aktiv ist.
Schrauben Sie die Blende neben dem vorhandenen Modul des W.A.M.S.-05 Systems ab und setzen Sie dafür das Empfangsmodul RM-105 ein oder tauschen Sie ein defektes Modul gegen ein neues. Belegung der 10 Leiterbahnkontakte (von links nach rechts) [1]: Funktion Funktion...
- download the latest version of the user manual from the Internet 1. INTRODUCTION Thank you for having chosen the OMNITRONIC receiver module RM-105. If you follow the instructions given in this manual, we can assure you that you will enjoy this device for many years.
2. SAFETY INSTRUCTIONS This device has left our premises in absolutely perfect condition. In order to maintain this condition and to ensure a safe operation, it is absolutely necessary for the user to follow the safety instructions and warning notes written in this user manual. Important: Damages caused by the disregard of this user manual are not subject to warranty.
4. DESCRIPTION OF THE DEVICE SET button LCD screen To activate the adjusting mode for the transmission Indicates transmission channel radio channel and to confirm. frequency. P/Q buttons Diversity LED A/B To adjust the frequency. To indicate the frequency The red or green LED indicates which of the two internal instead of the channel on the display keep one of these reception antennas [A/B] is currently active.
Unscrew the plate next to the existing receiver module of the W.A.M.S.-05 system and insert the receiver module RM-105 instead or replace a defective module with a new one. Occupation of the 10 strip conductor contacts (from left to right) [1]:...
