TECHNICAL DATA

Supply voltage
Operating temperature
Image compression
Image resolution
Live video frame rate
Recorded image frame rate
Image sensor
Local storage
Motor angle
Viewing angle
Minimum light level
Infrared LEDs
Visibility in low light conditions
Wireless technology
Network connection
Network protocols
Simultaneous viewing
Safety
Minimum hardware configuration
Number of cameras per application
To discover all the functions offered by your VISIDOM ICM100 camera, please download the
user instructions from the main Somfy VISIDOM menu. (Fig.14)
Copyright © 2015 Somfy SAS. All rights reserved.
Downloaded from www.Manualslib.com
Camera parameters
Audio/video parameters

Network parameters

manuals search engine
5V 1.5A via the 230 V mains adapter
From -10°C to + 50°C
H.264
HD 1280x720
25 fps (VGA) / 10 fps (HD)
20 fps (HD)
CMOS Mega pixel
Micro SD card - 32GB maximum
(card provided: 8 GB)
H: 270° - V: 90°
H: 75°±3° - V: 45°±3°
1 to 8 lux
5 LEDs with automatic activation according to light level
5 metres
IEEE 802.11 b/g
Ethernet (10/100 Base-T/Base-TX); Wi-Fi
TCP/IP, UDP, SMTP, NTP, DHCP, ARP
3 simultaneous sessions
WEP/WPA /WPA2 (TKIP, 128-bit AES)
1.5 GHz dual core
8 (maximum)
