Step 9. Power On the SCXI Chassis
If you are using an SCXI chassis, the chassis power switch is shown in Figure 2,
you are using a PXI/SCXI combination chassis, the PXI and chassis power switches are shown in
Figure 3, PXI/SCXI Combination Chassis
Windows recognizes any newly installed device the first time the computer reboots after hardware is
installed. On some Windows systems, the Found New Hardware wizard opens with a dialog box for
every NI device installed. Install the software automatically (Recommended) is selected by default.
Click Next or Yes to install the software for each device.
When the controller recognizes a USB device such as an SCXI-1600 module, the LED on the module
front panel blinks or lights up. Refer to the device documentation for LED pattern descriptions and
troubleshooting information.
Step 10. Confirm That the Chassis and Modules Are Recognized
Complete the following steps:
1. Double-click the Measurement & Automation icon on the desktop to open MAX.
2. Expand Devices and Interfaces then expand NI-DAQmx Devices. If you are using a remote RT
target, expand Remote Systems, find and expand your target, and then expand Devices and
Interfaces.
3. Check that your device appears under Devices and Interfaces.
1 When a device is supported by both Traditional NI-DAQ (Legacy) and NI-DAQmx and both are installed, the same
device is listed with a different name under My System»Devices and Interfaces.
2 Only NI-DAQmx Devices are listed under Remote Systems»Devices and Interfaces.
If your device does not appear, press <F5> to refresh the view in MAX. If the device is still not
recognized, refer to
Troubleshooting
SCXI Quick Start Guide
Setup.
1
2
ni.com/support/install
section of this document.
10
SCXI Chassis
. If your chassis is not recognized, refer to the
Setup. If
