Connecting water hose
Step 1 :
• Close the water valve and remove the water line from the water tank.
• Connect the t-shaped connector to the water tank.
NOTICE Make sure that rubber packing is inserted in between.
Step 2 :
1
Regulator
• Connect the water line to the bottom of the "T" shaped connector.
NOTICE Please remove the regulator cover and regulate o-ring under the
following conditions:
• When the water dynamic pressure is lower than 0.05MPa.
• When the nozzle cannot work normally and water is low.
• Remove the regulator cover and regulate o-ring except the sealing o-ring.
• Insert the regulator component into the inlet pipe.
Must use the regulator cover and regulate o-ring when the water
CAUTION
pressure is bigger than 0.1MPa.
Sealing o-ring
Regulate o-ring
Regulator
cover
2
3
