Setting and using method

5. Indoor unit monitoring

n Monitoring operation and error status : Refer to below and
connect to the control device that you want to control.
1) Turn Off the 2
n Cooling, Thermal On Mode and Occupancy output : This relay
output Is for interlocking with economizer.
1) Turn ON the 2
Ú When Indoor unit is operating as Cooling Thermal On Mode Relay output is closed.
16 Dry Contact for setback
Downloaded from www.Manualslib.com
nd switch of SETTING_SW.
Local Supply
Operation Display
(Depends on Operation
display power type)
nd switch of SETTING_SW.
Cooling Thermal On Mode
manuals search engine
Power
AC or DC
Economizer
Local Supply
Power
Error Display
AC or DC
(Depends on Error
display power type)
