Setting and using method
3) Fan level setting mode
CONTROL_
MODE S/W
Ú When the indoor unit is operating with a Dry Contact For Setback, the fan level can be changed by other
controller when the fan level is set to low level and the indoor is in unlocked condition.
4) Power save mode
CONTROL_
MODE S/W
Ú When setting 9, A mode, the TEMP_SETTING must always be set to ON.
Ú Power save mode: Adjust the set temperature to +3°C for cooling and -3°C for heating.
14 Dry Contact for setback
Downloaded from www.Manualslib.com
Input A Input B
OFF OFF
ON OFF
7
OFF ON
ON ON
OFF OFF
ON OFF
8
OFF ON
ON ON
Input A Input B
OFF OFF
ON OFF
9
OFF ON
ON ON
OFF OFF
ON OFF
A
OFF ON
ON ON
manuals search engine
Operating mode
Indoor unit operating at low level, locked
Indoor unit operating at low level, unlocked
Indoor unit stopped, locked
Indoor unit stopped, locked
Indoor unit operating at low level, locked
Indoor unit operating at low level, unlocked
Indoor unit stopped, locked
Indoor unit prior operating condition maintained, unlocked
Operating mode
Indoor unit operating in power save mode, locked
Indoor unit operating in power save mode, unlocked
Indoor unit stopped, locked
Indoor unit operating not in power save mode, unlocked
Indoor unit operating in power save mode, locked
Indoor unit operating in power save mode, unlocked
Indoor unit stopped, locked
Indoor unit stopped, locked
