Temp cut-off
ON 80C
Ext. Temp
Int. Temp
C1: 3.75 C2:3.75V
C3: 3.76 C4:3.76V

12. Warning and error messages

It incorporates a various functions of protective and monitoring the system to
verify functions and the state of ist electronics. In any case of occuring error, the
screen displays the cause of error that is self-explanatory with audible sound.
REVERSE POLARITY
CONNECTION BREAK
SHORT ERR
VOL SELECT ERR
BREAK DOWN
BATTERY CHECK
LOW VOLTAGE
BATTERY CHECK
HIGH VOLTAGE
Displayed temperature cut-off function is turned on.
176F
The external temperature is displayed when the
temperature probe is used (optional part). Int
0C
temperature is displaying the internal temperature of
31C
the charger.
The battery is connected with each port through
cable; you can check voltage of each cell in the
battery pack. When the cable is connected with the
ports on the charger, the program will display voltage
of up to 4 cells.
Incorrect polarity connected.
Battery connection is interrupted.
Short-circuit of the output termination.
The voltage of the battery pack has been selected
incorrectly!
The charger has malfunctioned for some reason.
Seek professional advice.
The voltage is lower than which is set. Please check
the number of cells in the battery pack.
The voltage is higher than which is set. Please check
the number of cells in the battery pack.
-17-
