Led Indicator - D-Link DMC810SC Schnellinstallationsanleitung

LINK/ACT
LLCF (Link Loss Carry Forward)
When a device connected to the converter and the TP line loss the link,
the converter's fiber will disconnect the link of transmit, so that the
other ends will know that there is a linkage error on this end. And when
the Fiber line loss the link, the converter's TP will disconnected, and the
other end will know that there is linkage problem exist.
There is a default LLCF setting on this converter.
LLR (Link Loss Return)
When a device connected to the converter and the fiber line loss the link,
the converter's fiber will disconnect the link of transmit.
There is a switch to enable or disable the function of the media
converter.
Downloaded from www.Manualslib.com

LED Indicator
