NiCd Sensitivity
D.Peak
lower, there is a possibility of premature termination. Please refer the technical specification of the battery.
(NiCd default: 12mV, NiMH default: 7mV)
USB/Temp Select
Temp Cut-off
link the charger to your PC via an optional USB cable. This can utilize the optional software that can show
you the charge process at PC.
USB/Temp
Temp Cut-off
Waste time
CHG/DCHG
time to cool down before being subjected to the next process. The value ranges from 1 to 60 minutes.
Safety timer
ON
Capacity
ON
Key Beep
Buzzer
Input power low
Cut-off
6
Downloaded from www.Manualslib.com
This shows the trigger voltage for automatic charge termination of NiMH and
NiCd battery. The effective value ranges from 5 to 20mV per cell. If the trigger
Default
voltage is set higher, there is a danger of overcharging the battery; if it is set
(OPTIONAL) You can select the function of 3-pin port at left side of the unit. It
can be used temperature sensor port or USB port, selected at this screen. If
the port is assigned as a temp. port, an optional temperature probe contacting
80C
the surface of battery can be used. When it is selected as an USB port, you can
(OPTIONAL) You can set the maximum temperature at which the charger should
Select
allow battery to reach during charge. Once a battery reaches this temperature
Enabled
during charge, the process will be terminated to protect the battery.
The battery is on the cyclic process of charge and discharge can often become
warm after charge or discharge period. The program can insert a time delay to
5min
occur after each charge and discharge process to allow the battery adequate
When you start a charge process, the integral safety timer automatically starts
running at the same time. This is programmed to prevent overcharge the
battery if it proves to be faulty, or if the termination circuit cannot detect the
120min
battery full. Please refer the statement in below to calculate the time setting.
This program sets the maximum charge capacity that will be supplied to the
Cut-Off
battery during charge. If the delta-peak voltage is not detected nor the safety
5000mAh
timer expired by any reason, this feature will automatically stop the process at
the selected capacity value.
The beep sounds at every time pressing the buttons to confirm your action.
ON
The beep or melody sounded at various times during operation to alert different
ON
mode changes. These audible sounds can be on or off.
This program monitors the voltage of input DC battery. If the voltage drops
below the value you set the operation forcibly terminated to protect the input
10.0V
battery.
