LOAD DATA PrOgrAM

PROGRAM SELECT
LOAD DATA
LOAD [01] NiMH
14.4V
Load...
VAriOUS infOrMATiOn DUring THE PrOCESS
You can inquire various information on LCD screen during charging or discharging process. When you press DEC
button the charger shows the establishment of user settings. And also you can monitor the voltage of individual
cell by pressing inC button when the individual connection cable is linked to the Lithium battery being processed.
End Voltage
Capacity
ON
Safety Timer
ON
USB/Temp
USB
Ext.Temp
IN Power
4.14 4.16
0.00 0.00
12
Downloaded from www.Manualslib.com
This program calls back the data that was stored at "Save Data" program.
To load the data, press start/Enter key once to blink the data number field
and select the number using inC or DEC key then press start/Enter key for
more than 3 seconds.
Select the data number to be called back.
3000mAh
The data matched with the number will be displayed at this time.
Loading the data.
The final voltage will be reached at the end of process.
12.6(3S)
Cut-Off
5000mAh
200min
Select
The 3-pin port is assigned as an USB port.
Enabled
The external temperature only will be displayed when using the thermal
26C
probe.
Voltage
The present voltage of input power.
12.56V
Using the individual connection cable to the battery, you can check the
4.09
individual voltages of each cell in the battery pack. When connect the cable
to the port on the right side of the charger the program shows the voltage
0.00
of each cells for maximum 6 cells in sequence. To utilize this feature, the
battery pack must have output connector that linked to each cells.
