Specifications:

Feature
LEDs
colour mixture
voltage supply
power consumption
programs
DMX modes
dimensions (WxDxH)
weight

Troubleshooting:

Note! (Error during data transmission)
Never connect the DMX input or output to audio de-
vices such as power amplifiers or mixing consoles!
DMX cables enable trouble-free operation and the highest possible trans-
mission reliability of signal data. Do not use microphone cables.
The following overview is intended as an aid to rapid troubleshooting. If you are unsure,
contact the manufacturer, the dealer or appropriate specialist personnel. Never open the
device by yourself!
Symptom
No function
No reaction in DMX mode
If the specified corrections have not been successful, please contact our service staff. The cont-
act details can be found at www.musicstore.de.
Lightmaxx LED Color Bar Stripe
252 10 mm LEDs
RGB
AC110-240V/ 50, 60 Hz
30W
auto, sound, DMX
2-, 3-, 4-, 5- or 12-channel
1018 x 63 x 87 mm
1 Kg
Troubleshooting
Check the mains connection and its fuse.
Check the cable connections.
Überprüfen Sie die Kabelverbindungen.
If available, try an alternative DMX controller.
