5. SPECIFICATIONS A ND DECLARATION OF CONFORMITY
ACTIVE s.r.l. Zona Artigianale - 26037 S. Giovanni in Croce (CR)
declare under its own responsability that the machine :
HEDGETRIMMER H23T
MODEL
23
DISPLACEMENT cm³
0.9 / 1.2
POWER Kw / CV
CARBURETOR DIAPHRAGM TYPE WALBRO WYC PRIMER DEVICE
IGNITION DIGITAL
FUEL TANK CAPACITY 0.52 Lt.
54 mm. (Heavy duty type)
CLUTCH
ANTIVIBRATION - SYSTEM YES (Inside of the clutch housing)
THROTTLE CONTROL Lockout safety device with automatic release (ROTATING TYPE)
BLADES LENGHT 600 and 750 mm
REDUCTION GEAR Two reductions (greased)
BLADES PITCH 35 mm
Both sides
CUTTING SYSTEM
WEIGHT Kg. 5,4 (md. 600 mm blades length) - 5,65 (md. 750 mm blades length)
is complies with the requirements established by directive 2006/42/CE, 89/336/CE,
2004/108/CE, 2000/14/CE, 2002/44/CE
We certify that the power level complies with the requirements established by directive
CE/2000/14, annexe V, and according with the norm EN ISO 22868
MODEL
PRESSURE LEVEL

POWER LEVEL

VIBRATION LEVEL
LpA av - EN ISO 22868 LwA av - EN ISO 22868
EN ISO 22867
5,0
23 cm³ 99 dB (A)
110 dB (A)
ALBERTO GRIFFINI
PRESIDENTE
ACTIVE S.r.l.
Via Delmoncello, 12
26037 San Giovanni in Croce (CR) - ITALY
10/10/2008
19
