(Optional) Configuration without
Windows 95 or Windows NT
4
5
Downloaded from
www.Manualslib.com
Access Local Management from the
Console port
1 Use a null-modem cable to connect the Console port to a COM port on a PC.
Console
9600-8-N-1
2 Open a VT-100 compatible terminal emulation program and set the communication parameters:
9600 baud, 8 data bits,1 stop bit , No parity, Xon/Xoff flow control (unrelated to the switch's
flow control feature).
3 Press <Enter> to display Local Management.
4 Select Administrator, and press <Enter> to access the configuration options.
5 When prompted for a password, press <Enter>.
The switch is delivered with no password as default. We advise you to later define a password to
prevent unauthorized access to the switch's configuration options. The Local Management main
menu screen is now displayed.
You are now ready to configure the switch.
Configure using Local Management
1 Select Configuration>Quick setup to access the Local Management configuration program.
2 Type the IP address, press <Enter>.
The default IP address is 192.0.2.1, which you should change to avoid possible IP address
conflicts.
3 If using subnetting, type the network (subnet) mask.
4 Follow the instructions given on the screen. Press <Enter> to move to the next field.
5 Select Configuration>Save to flash memory.
This saves the new configuration in the switch's Flash Memory and makes the settings
permanent.
manuals search engine
Note: a null-modem cable is provided with the Switch.
