Quick Start
1
2
3
Downloaded from
www.Manualslib.com
Install the Express
550T Switch
Place the switch in a rack or on a shelf or
table, plug the cord in, and turn the power
on.
Connect devices
to the Switch
When connecting network devices to the
switch, make sure you use the right type of
cable (straight-through or crossover). See
the diagram to the right.
Check port LEDs
•
Verify that the Power LED is green.
•
The Port LEDs reflect the state of each port:
Green
Orange
Off
Off
Blinking randomly
Off
Solid
Off
Blinking randomly
Blinking randomly
Off
Solid
Solid
Solid
manuals search engine
Slot A
1
2
3
4
5
Rubber feet for shelf or table placement.
Brackets and screws for standard
19-inch equipment rack placement.
switch
switch
switch
Meaning
Port enabled, no link.
Port enabled, Rx/Tx traffic, link pulse active.
Port enabled, link pulse active.
Collision detected. Port enabled, link pulse active.
Port disabled by hardware failure or management.
Port disabled by a fault, or no hardware connected.
Slot B
Orange
LEDs
Green
Intel Express
Off
10 Mbps
Half duplex
Solid
100 Mbps
Full duplex
550T Routing
Switch
Port Status
Status
Power
LEDs
Green
Orange
Temperature
Solid
Link
Disabled
Reset
Blink
Activity
Collision
RPS
6
7
8
Console
9600-8-N-1
1661
PC or
server
printer
switch
or hub
1
