Installation on outside sliding doors
• Place rotaing bracket on the door jam of the stationary door.
• Mark and drill 1/16" holes and attach bracket to door jam with screws provided.
• With other end of bar in the saddle bracket, extend bar to inside edge of sliding door, hold in
horizontal position.
• Mark and drill 1/16" holes and install screws through saddle catch and Anti-Lift Lock
(if desired) into door.
Installation on outside sliding doors
Rotating bracket
• Place rotating bracket against inside edge of non-moving door. Saddle installs on inside
frame of movable door. Care must be taken that the saddle is positioned at least 2 inches
above the sliding door handle.
4
Anti-lift lock(Optional)
Release lever
Rotating bracket
Door Jamb
Outside sliding door
Anti-lift lock(Optional)
Release lever
Door Jamb
Outside sliding door
Saddle
Saddle
