DEFA 2000 Betriebsanleitung Seite 3

FRONT
9 6
3
7 8
6
1. Switch (ON/OFF)
2. Remote connection
3. Power indicator diode
4. "Overload" diode
5. "Over temperature" diode
6. AC connection, 230VAC
3
1
2000W
2500W
3000W
5
4 2
1
5
2
4
BACK
10
10 9
7. Red terminal, positive (+)
8. Black terminal, negative (-)
9. Chassis grounding
10. Cooling fan
7 8
10
10
3
