FUNCTIONAL INSTRUCTIONS
OPTICAL
INPUT
BROWN/BLACK
SUB R –
BROWN
SUB R +
ORANGE/BLACK
SUB L –
ORANGE
POWER
SUB L +
PURPLE/BLACK
REAR R –
PURPLE
REAR R +
REMOTE FEATURES AND OPERATIONAL CONTROLS
1
With this knob the overall volume of the sound system can be controlled. If you press and hold the knob for 3 seconds, the bass
level of output SUB OUT (G / H) can also be controlled.
2
The LED display shows the values when turning the knob (# 1) or the number of the selected settings.
3 With the two MODE buttons you can choose between the settings, which are stored in the DSP.
Use the buttons
4
With the INPUT SEL. button you are able to switch between the signal inputs of the audio sources MAIN, AUX IN and OPTICAL.
MAIN is the input LINE IN (Page 21, #6) and HIGH LEVEL INPUT (Seite 21, #7) as well as SUB IN (Page 21, #5).
Important note: If the remote control is not connected, the DSP works with setting 1 and no settings can be
saved.
CABLE SET HIGH LEVEL INPUT
X– DSP DIGITAL SOUND PROCESSOR
SUB R
SUB L
REMOTE
A B C
1
VOLUME
–
to select the desired setting and confirm with OK (# 3).
ASSIGNMENT
MAIN INPUT
RR RL
FR
HIGH LEVEL INPUT
OUTPUT
D E F
2
X– DSP
+
MODE OK
3
WHITE
FL
FRONT L +
AUX
INPUT
WHITE/BLACK
FRONT L –
GREY
FRONT R +
GREY/BLACK
PC CONNECT
FRONT R –
GREEN
REAR L +
G GREEN/BLACK H
REAR L –
MAIN
AUX
OPTICAL
INPUT
4
USB
