Foldable­side­tables
(optional equipment)
Disconnect the gas hose every time before unfolding the side table!
In this way you avoid pinching the gas hose.
1. All foldable side tables must be locked in place horizontally to operate your
grill.
2. Make sure that each foldable side table is locked in position and cannot fold
down itself (see Fig. below).
3. After connecting the gas hose to the plug coupling, check the connectors
along with gas hose for leaks according to the section "Leak check".
Gas hose between grill and side table:
• The quick plug coupling is used for the simple and quick connection of the gas hose to the grill.
No other tools are required.
• The quick plug coupling is a safety-relevant component.
The gas is automatically shut-off upon disconnection.
Folding­side­table­up­/­Connecting­the­gas­supply
(before start-up)
1. Close the shut-off valve at the gas cylinder.
2. Take the side table at both sides and fold it up into a horizontal position (1).
3. Then carefully slide the side table forward and push it downwards (2) as far as the stop (3).
0
Always seal the coupling on both sides with the protective covers when not in use!
All connections of the quick plug coupling must be kept free of dirt. Even slight contamination can
cause leaks at the connections. Therefore, they must always be kept clean.
2
3
