ENG
FUNCTION
The LED light will switch on during twilight or darkness when the motion detector
detects infrared radiation given off by people passing by.
User can turn the control knob TIME to adjust the duration of the illumination from
approx. 3 seconds to 7 minutes (+/-10%).
User can turn the control knob LUX to adjust the daylight level at which to activate
the motion detector.
Note! To save battery working time use low LUX so light does not turn on in daytime
and only when it is dark.
Note: Once the light is activated by the motion detector, any subsequent detection
will restart the timed period again from the beginning.
Note: The motion detector responds to heat radiation. When outdoor temperatures
are low, it is more sensitive to body heat than when outdoor temperatures are warm.
Note: If the light is not activating in nighttime, a street light, house light or other ambient
light could be affecting activation. Turn the control knob LUX towards position  to
increase the daylight level. If the light is unnecessarily activating in daytime, turn the
control LUX towards position  to decrease the daylight level.
Note: Regularly clean the motion detector to ensure proper functionality (refer to
"Cleaning and Care").

INSTALLATION

When selecting the exterior mounting location, pay attention to the following:
Note: The included mounting material is suitable for solid concrete or masonry construction.
Other wall substrates may require additional fastening materials.
Note: An electric drill is required.
CAUTION! RISK OF INJURY! Please read the operating instructions for your drill.
CAUTION! Ensure that you do not damage any electrical cables in the wall or ceiling.
4
