EC-3 EC-3100, EC-3101 & EC-3105 Electronic Faucets
1 1 A Aerator, Vandal Resistant
2 2 Adapter for Non-Splash Aerator A
3 Washer 3 W
4 4 Angled Sensor w/ Cable A
5 5 Inlet Hose for use with EC-3100 I
1/2" NPSM-F x 1/4" NPSM-F x 18" Long
5 5 Inlet Hose for use with EC-3101 & EC-3105 I
1/2" NPSM-F x 3/8" NPSM-F x 30" Long
6 6 C Control Module
7 7 A A/C Transformer
8 8 M Manual Mixing Valve
9 9 S Supply Hose, 9/16-24 UN Female x 1/2" NPSM
10 V 10 Vandal Resistant Key
EC-3102, EC-3103 & EC-3104 Electronic Faucets EC-3
1 1 A Aerator, Vandal Resistant, 2.2 GPM
2 2 Angled Sensor w/ Cable A
3 3 Inlet Hose, Faucet, 1/2" NPSM-F x 1/4" NPSM-F I
4 4 Control Module C
5 5 A A/C Transformer
6 6 M Manual Mixing Valve
7 7 S Supply Hose, 9/16-24 UN Female x 1/2" NPSM
8 V 8 Vandal Resistant Key
EC-3107 Electronic Faucets EC-3
1 1 A Aerator, Vandal Resistant, 2.2 GPM
2 2 Adapter, 3/8" to Aerator A
3 Washer 3 W
4 4 A Angled Sensor w/ Cable
5 5 Inlet Hose, Faucet, 1/2" NPSM-F x 1/4" NPSM-F I
6 6 Control Module w/ Filter Tee C
7 7 A A/C Transformer
8 8 M Manual Mixing Valve
9 9 S Supply Hose, 9/16-24 UN Female x 1/2" NPSM
10 Vandal Resistant Key 10 V
Part Number Guide
B-0199-06
044A
001043-45
019174-45
016297-45
016325-45
019944-45
5EF-0002
5EF-0006
5EF-0005
015425-45
B-0199-08
019174-45
016297-45
019944-45
5EF-0002
5EF-0006
5EF-0005
015425-45
B-0199-06
001043-45
019174-45
016297-45
019944-45
5EF-0002
5EF-0006
5EF-0005
015425-45
9
