7. AUDIO INPUT

8. REMOTE CONTROL
OPERATING INSTRUCTIONS
1. ENABLE RECORD
2. ERASE ALL PROGRAMS
3. CLEAR MEMORY
4a. Record SCENE program
7
Downloaded from www.Manualslib.com
Line audio input 100mV—1Vpp.
Full on and Black out remote control connection using 1/4"
Stereo Jack.
1) Press and hold the Record key.
2) Press Flash1, Flash 5, Flash 6 and Flash 8 in sequence.
3) Release Record, the led is lighting, recording is ready.
1) Press and hold the Record key.
2) Press Flash 1, Flash 3, Flash 2, Flash 3 in sequence.
3) Release Record.
1) Press the Record key and press the REC CLEAR key.
2) Release Record and Rec Clear at the same time.
Enable Record (see N° 1)
•
Press MODE SELECT until the green led is on. (1-24 single/
•
preset park)
Choose a page (1, 2, 3 or 4)
•
Bring both MASTER faders fully up (A=open, B=closed)
•
Prepare your scene, adjusting faders 1 to 24
•
Press RECORD: the scene is memorised but has no number
•
yet
Bring both MASTER faders fully down (A=closed, B=open)
•
Press and hold RECORD
•
Choose a Scene number (1 to 12) by pressing one of the
•
bottom FLASH buttons
Release the RECORD button
•
The SCENE is recorded
•
