20. DETAILED DISCRIPTION
CMX 24
Downloaded from www.Manualslib.com
1) Fade Time: the time that is needed to go from 0% to
100% or from 100% to 0%.
2) Single Mode: the program is executed step by step.
The number of each step appears on the display.
The speed is controlled by the Speed slider.
3) Mix Mode: all selected programs will run
simultaneously, each at their respective speed.
4) When the CHASE//SCENES led lights up, you can
select a program by using the sliders of Preset B. When
you put one of the Preset B channels in BLIND MODE then
its slider and the slider of Master A will control its output
level. The maximum level of the program is maintained
until you switch back the channel with the HOME key.
5) Fade Time & Speed Time:
A. When time is more than 1 minute, two dots appear.
E.g.: 1 minute and 15 seconds = 1.15.
10 minutes = 10.0.
B. When time is less than 1 minute, one dot appears.
E.g.: 11,5 seconds = 11.5
0,55 seconds = 0.55
6) Transmit and receive data
A. Open loop
TRANSMITTER
MIDI OUT
B. Closed loop
TRANSMITTER
MIDI OUT MIDI IN
manuals search engine
RECIEVER
MIDI IN
RECEIVER
MIDI OUT MIDI IN
