TECHNICAL SPECIFIATIONS
Model
Voltage
Input power
Speed
Max. Drilling capacity
Max. Drilling capacity
Max. Drilling capacity
Sound pressure level
Sound power level
Vibration level a
h,D
Chuck
NOISE/VIBRATION INFORMATION
Measured sound values determined according to EN 62841.
Wear hearing protection!
Vibration total values (triax vector sum) determined according to EN 62841:
The vibration emission level given in this information sheet has been measured in accordance with
a standardised test given in EN 62841 and may be used to compare one tool with another.
It may be used for a preliminary assessment of exposure.
The declared vibration emission level represents the main applications of the tool. However if the
tool is used for different applications, with different accessories or poorly maintained, the vibration
emission may differ. This may significantly increase the exposure level over the total working
period.
An estimation of the level of exposure to vibration should also take into account the times when
the tool is switched off or when it is running but not actually doing the job. This may significantly
reduce the exposure level over the total working period.
Identify additional safety measures to protect the operator from the effects of vibration such as:
maintain the tool and the accessories, keep the hands warm, organization of work patterns.

OPERATION

Before use
Before making assembly, changing and adjustment for any accessory, disconnect the tool from
the mains supply to avoid any unintentional starting.
Please always check the mains supply voltage before use! It must correspond with the rating label
on the appliance.
Remove any packing material and loose parts from unit.
Check the accessories before use. It should be fit with the machine and your purpose.
Auxiliary Handle
The auxiliary handle can be mounted on the left or right side of the chuck. Mount the handle at the
flange behind the chuck and tighten it firmly in its desired position.
Depending on the working method, the auxiliary handle can be adjusted in different positions.
CAUTION!
The machine should be used only with both handles.
Do not continue to use an auxiliary handle if it is damaged.
Depth Gauge
The drilling depth can be set with the depth gauge.
Insert a drill bit into the chuck and clamp it. Loosen the auxiliary handle by turning it clockwise and
insert the depth gauge into the intended hole. Move the depth gauge until the distance between
6
994058 (SCID133106D)
230-240V~50Hz
600W
0-3000/min
Steel 10 mm
Concrete 13mm
Wood 25 mm
L =93,4 dB(A), K =3 dB
pA
L =104,4 dB(A), K =3 dB
wA
a = 25,987 m/s² k= 1,5 m/s²
h
13mm 2-sleeve keyless chuck
