Greggersen Forano AGFS Bedienungsanleitung Seite 6

Anaesthetic gas scavenging system AGSS
Technical data
Type:
Connections:
Capacity:
Gasconsumption:
Color:
Installation:
Guidelines:
Important information
• Comply with DIN EN ISO 7396-2 for the installation of AGSS systems!
• Comply with TRGS 525 for operating the anesthesia gas exhaust system!
• Use only original GREGGERSEN spare parts!
Service/Maintenance
External disinfection with a cloth is sufficient for all chrome-plated brass parts. Clean plastic parts
with a common disinfectant solution and follow manufacturers instructions. Let outlets and plug
dry completely before using them again.
Prior to each use, make a visual check of the outlets (external damages). Outlets and plug should
be controlled at least once a year (capacity, function); in very frequently used areas accordingly
more frequently!
Failures and damages may only be remedied by authorized expert personnel. For repairs, use only
original GREGGERSEN spare parts!
Greggersen Gasetechnik GmbH, Bodestraße 27-29, 21031 Hamburg, Germany, Fon +49 (0)40-73 93 57-0
All metal design, plug-in ejector for generating a vacuum, one-hand
operation for plugging in and out, visual signal for operating control,
integrated valve for capacity adjustment.
flush mounting/hollow wall: stainless steel installation housing, stainless
steel front plate with visual signal.
Supply lines
pressure gas line:
exhaust line:
Outlet/ejector
pressure gas supply:
ejector:
anesthesia gas exhaust: 15 mm hose
visual signal:
at least 50 l/min at propellant pressure of 500 kPa
power gas: ≈12 l/min at flow 50 l/min
magenta-red designation, according to DIN EN ISO 9170-2
• flush-mounting or hollow wall mounting
• ceiling supply systems
• wall supply systems
dimensions see annex
DIN EN ISO 9170-2
DIN EN ISO 7396-2
Medical Devices Directive 93/42/EEC; Classification: IIa
04.12.13/GR/ AGFS-Forano.dts.eng.pdf
Cu-tube 8x1
Cu-tube 15x1
coupling for 4 mm PA-hose
or 6 mm hose nozzle
coupling for 4 mm PA-hose
or 6 mm hose nozzle
coupling for 4 mm PA-hose
6
