PCM VDF701-IK Betriebsanleitung Seite 2

English
1. To fix the tool holder to the machine,
introduce the shank and use the pins for
the positioning.
Then tighten the 4 screws of fixations
(A)(Important, make sure that the screws
have the same strength of tightening).
2. Then tighten the 4 screws of fixations
(B)(Important, make sure that the screws
have the same strength of tightening).
Zone industrielle C
Rte du Grammont 101
CH-1844 Villeneuve
Mode d'emploi
Operating instructions
Betriebsanleitung
Istruzioni per l'uso
VDF701-IK
3. Then tighten lightly the fixing screws
PCM WILLEN SA
SWISS MADE
Copyright © PCM Willen SA.
Garant:
RBT
Validation : 04.07.2017
(important, make sure that the screws
have the same clamping force).
Tél ++41 21 967 33 66
Fax ++41 21 960 38 95
http://www.pcm.ch
email: office@pcm.ch
Document :
VDF701-IK Mode
d'emploi
Page : 2 de 4
