WARNINGS
• Please read these instructions before assembly and use of this product.Please keep these instructions for future reference.
• To prevent serious injury or death: Use only for a child who is able to hold head upright unassisted and who is not ableto walk or climb out of product.
• Never leave child unattended. Always keep child in view while in product.
• Never use near steps, pools, hot surfaces or areas that may be hazardous to a child.
Product may move during use.
• To avoid tip-over, place product on a flat, level surface.
• Strings can cause strangulation!
• DO NOT place items with a string around child's neck, such as hood strings or pacifier cords.
• DO NOT suspend strings over product or attach strings to toys.
• Adult assembly is required. Tool needed for battery installation: Phillips screwdriver (not included).
• Requires three "AN' (LR6) alkaline batteries (not included) for toy operation.
• Use only for a child: who is able to hold head up unassisted; who is not able to climb out; who weighs less than 11,3 kg and is less than 81 cm in height.
• Before assembly and each use, inspect this product for damaged hardware, loose joints, missing parts or sharp edges. DO NOT use if any parts are missing or broken.
I. PARTS LIST
1. Base Tubes (3pcs); 2. Hin ged Bases(3pcs); 3. Frame; 4. Seat; 5. Pad; 6. Electronic Toy; 7. Hanging Cloth Toys (2pcs); 8. Rainbow Top; 9. Peek-a-boo Tiger Base;10. Lizard Toy; 11.
Dragon y Toy;
II. ASSEMBLY INSTRUCTIONS
2.1. Place a hinged base on a at surface. While pressing the button on a base tube, insert it into the short tube on the hinged base. Continue to slide the base tube into the short tube
until you hear a "click". Repeat this procedure to assemble the other base tube to the other hinged base. A- Base tube; B- Short tube; C- Hinged base;
2.2. The nal base assembly of this product is a circle. Position the hinged base assemblies so that they form a half circle.
2.3. Locate the tapered tube and regular tube on the hinged base assemblies. While pressing the button on the tapered tube, insert it into the regular tube. Continue to
slide the tapered tube into the regular tube until you hear a "click". D- Tapered tube; E- Regular tube;
2.4. While pressing the button on the small base tube, insert it into the hinged base assembly tube. Continue to slide it until you hear a "click". C- Hinged base; G-Hinged base
assembly tube;
2.5. While pressing the button on the hinged base assembly tube, insert it into the large base tube. Continue to slide the hinged base assembly tube into the large base tube until you
hear a "click". G-Hinged base assembly tube; F- Large base tube;
2.6. Position the seat so that the inside (ribbed side) is up and the star mark is toward you. Fit the yellow slots on the pad to the seat pegs on either side of the star mark. A- Seat; B-
Peg; C- Star Marking; D- Yellow slots; E-Pad;
2.7. Pull the pad through the seat. Wrap the edges of the pad around the outside of the seat. A- Seat; E-Pad;
2.8. Fit the other six slots in the seat pad to the corresponding pegs on the seat.
2.9. While pressing the button on a frame tube, insert it into a base tube. Continue to slide the frame tube into the base tube until you hear a "click". Pull up on the frame tube to be
sure it is secure. Repeat this procedure to assemble the two remaining frame tubes to the base tubes. A- Frame tube; B- Base tube;
2.10. Insert and "snap" the seat with pad into the seat ring. Pull up on the seat to be sure it is secure. C-Seat ring; D-Seat with pad;
2.11. Hint: You may want to install batteries inside the electronic toy before completing this assembly step. Please refer to the Battery Installation section. Insert and "snap" the
rainbow into the slots in the peek-a-boo tiger base. Insert and "snap" the toys into the seat ring, as shown.
2.12. BATTERY INSTALLATION
Hint: We recommend using alkaline batteries for longer battery life.
In exceptional circumstances, batteries may leak uids that can cause a chemical burn injury or ruin your product. To avoid battery leakage:
• Loosen the screws in the battery compartment door with a Phillips screwdriver and remove the battery compartment door.
• Insert three "AA:' (LR6) alkaline batteries into the battery compartment.
• Replace the battery compartment door and tighten the screws.
• When sounds or lights become faint or do not work at all, it's time for an adult to replace batteries.
• If this product begins to operate erratically, you may need to reset the electronics. Slide the power/volume switch o and then back on again.
III. SEAT HEIGHT ADJUSTMENT
3.1. Place your child in the seat. Check the distance between your baby's feet and the oor. Your child's toes should touch the oor (without bouncing). If your child's entire foot is
touching the oor or the toes are not touching the oor at all, adjust the height to any of three positions (one for the smallest child and three for the tallest child).
3.2. Remove your child from the seat. Lift the seat ring so the bottom faces you. Locate the strap bar and pull it open. A- Strap bar;
3.3. Pull the strap to the desired height. B- Strap;
3.4. Fit the strap bar into the desired slot in the strap. C-Slot;
3.5. Push to "snap" and fasten the strap bar. Repeat this process to attach the other two straps to the seat ring. IMPORTANT! Make sure all three straps are adjusted
to the same height.
3.6. MODE AND POWER SWITCH
Slide the power/volume switch to: • On with low volume • On with high volume
Slide the mode switch to: • Baby's jumping and spinning activates lights, sounds, and music! • Baby's jumping and spinning activates ve minutes of lights, sounds, and music.
VI. CARE AND CLEANING
The seat pad is machine washable. Wash it separately in cold water on the gentle cycle. Do not use bleach. Tumble dry separately on low heat and remove promptly.
• The frame, seat, seat ring, straps and toys may be wiped clean using a mild cleaning solution and damp cloth. Do not use bleach. Do not use harsh or abrasive cleaners. Rinse
clean with water to remove soap residue. Do not immerse the electronic toy.
Remove the Seat and Pad
• Lift the seat ring. While pressing near any notch on the seat, pull the seat from the seat ring. Tum the seat over. Remove the pad slots from the pegs on the seat. Remove the pad.
Replace the Seat and Pad
• Please follow the Assembly instructions.
ENGLISH
