Getting Started

Before you start using your SignalTEK 10G, follow the steps below to ensure
you take advantage of all the features your SignalTEK 10G has to offer.
1. Press the power button on both units.
2. Fully charge the display and remote units using the power supply included
in your case.
3. Connect the display and remote units using the supplied ethernet cable.
4. Choose your language via
5. Pair the remote unit with the display unit via
status connection will light up blue once successfully paired.
6. Set the link speed to Auto in the display unit via
RJ45 - Link Speed
7. Cable Qualification Test: Connect the display unit directly for cable
qualification test
8. Network Bandwidth Qualification Test: Connect the display unit and the
remote unit to the network (switches)
9. IP Network Test: Connect the display unit to the network and set the
IP address to Dynamic (DHCP) via
Assignment
10. For optical interface involved test, make sure the SFP used with the
tester is matching the fiber and other SFP's type and signal level within
the Rx power range. MGK series SFP Kit (to be ordered separately) is
recommended to assure the correct measurement results.
Settings - Set Language.
Settings - Network - IPv4 - IP
Proof of Performance
Settings - Pairing. The
Settings - Network -
EN
9
