Transmission - Cable Data Test
EN
1. Connect a cable under test (Fibre duplex/simplex via SFP or Copper)
between display and remote units.
2. Pair the remote unit with the display unit via
status connection will light up blue once successfully paired.
3. Set link speed to Auto via
4. Click: ANALYZE - Cable Data - Settings - Expected line rate 10G and
frame size 1518 - Tick - Return to test page - press Test
5. Save the results
1
10
www.idealnetworks.net
Settings - Network - RJ45 - Link Speed
2
Settings - Pairing. The
