Output Current
Battery Charge
Current
Mains LED
Fault LED
Max Mains Input
Current (at 90Vac)
Mains Input Fuse
Output Fuse**
Tamper Rating
** Module Fuse
Operating Instructions
This unit is intended for use by Service Personnel only - There are NO USER SERVICEABLE parts
inside.
The green Mains LED will be illuminated whilst the mains supply is present. In the event of a fault
condition, the red Fault LED will be illuminated (model dependent).

Maintenance

There is no regular maintenance required of the PSU other than periodic testing and replacement of the
standby battery. Reference should be made to the battery manufacturer's documentation to
determine typical/expected battery life with a view to periodic replacement of the battery.
If the output of the PSU fails the cause of the failure should be investigated e.g. short circuit load. The
fault should be rectified before restoring power to the PSU. The fuses may need to be replaced. Ensure
the correct fuse rating and type is used.
Risk of explosion if battery is replaced by an incorrect type.
Dispose of used batteries according to the battery manufacturer's
instructions and all local and national regulations.
The packaging supplied with this product may be recycled.
Specifications subject to change without notice
Technical Support Line +44 (0)2392 696638
© 2013 Elmdene International Ltd
Model Specification Table
G13801N G138015N
1A 1.5A
0.5A 0.5A
√ √
√ √
0.8A 1.0A
T2.0A T2.0A
F1.0A F1.6A
0.05A 0.05A
24vdc 24vdc
CAUTION
Please dispose of packaging accordingly.
www.elmdene.co.uk
G13802N G13803N
2A
0.5A 0.5A
√
√
1.0A 1.2A
T2.0A T2.0A
F2.0A F3.15A
0.05A 0.05A
24vdc 24vdc
G1380xN-y-s PAK200500 Issue 01D
G13804N
3A 4A
0.5A
√ √
√
X
1.8A
T3.15A
F4.0A
3A
125vdc
G13805N
5A
0.5A
√
X
2.0A
T3.15A
F5.0A
0.05A
24vdc
Feb 2013
