INSTALLATION
Fig. B
Fig. C
25mm
Minimum
10mm
500x50mm
Fitting the plate over non-ventilated oven is prohibited
Downloaded from www.Manualslib.com
1 2 3
80mm
manuals search engine
1 - table top
2 - cooktop sealing
3 - ceramic plate
Fitted in the top of a carrying cupboard
500x10mm
Fitted in a working top over an oven
with ventilation
500x10mm
44
5 10mm ÷
5 10mm ÷
