Owner's manual
Method 2: standard HDMI
If the TV does not support ARC,
soundbar can be connected
with standard HDMI cable.
1. Connect the HDMI to HDMI
output on the soundbar and
to TVs HDMI input.
2. Connect external devices to
soundbars HDMI input.
Connecting with optical socket
1. Remove the protective cap from optical socket.
2. Connect the optical cable to the TVs optical out socket and the
OPTICAL socket on the soundbar.
Connecting with COAXIAL socket
Plug the coaxial cable to soundbars socket and to the TVs socket.
Caution: the device may encounter problems while playing through
coaxial source. Make sure that the sound settings in external device
are set to PCM or Dolby Digital (refer to user manual of the external
device). If the soundbar cannot play the sound, there display will
show "NO SUPPORT" message.
COAXIAL OPTICAL
HDMI IN
HDMI OUT
(eARC/ARC)
or
HDMI IN 1 HDMI IN 2
HDMI OUT
EN
23
