Night Light; Night Vision; Monitor Setup; Power Supply - Biosentronics Snuza VIDEO Bedienungsanleitung

4.3 Night light

Press the night light button; the night light LEDs will remain ON (see Fig 6).

4.4 Night vision

The camera has nine high-intensity LEDs for picking up clear images in the dark. When the
built-in photo sensor detects low ambient light levels, the LEDs will automatically activate.

5. MONITOR SETUP

5.1 Power Supply

The monitor uses 3.7V 1050mAH (Li-ion) battery or the household AC power current.
Loading the Batteries
1. Open the battery compartment cover on the rear of the monitor (see Fig 7).
2. Insert the battery, ensuring the polarity is correct (see Fig 7).
3. Close the battery compartment cover, and ensure it is securely locked.
4. Turn the monitor ON (see Fig 7).
Note 1: When power is sufficient, the light is red; when the battery is low, the LED light
will start blinking.
Note 2: Remove the battery from the monitor if you do not plan to use it for a prolonged
period of time.
5. Adjust the volume to a comfortable level.
Using AC Power
1. Plug one end of the provided power adapter into a wall outlet and the other end into the
bottom of the monitor (see Fig 8).
Note: Use the adapter labeled OUTPUT: 6V DC with the monitor.
2. Turn the monitor on (see Fig 8).
3. Adjust the volume to a comfortable level.
Note 1: When charging starts, the 'Power' LED will appear blue. When charging is
finished (fully charged), the 'Power' LED will turn red.
Note 2: When the camera and monitor are linked, the 'Link' LED will turn green;
otherwise the 'Link' LED will flash red.
Note 3: 'OUT OF RANGE' will display on the LCD screen if the monitor exceeds the range
(unlink) (see Fig 9).
