OPERATING THE REMOTE CONTROL
RGB remote control (Figure F)
Button
Function
POWER ON/OFF
This is the on/off switch for all zones. The most recent selected colour or colour sequence
F1
(On/off)
program remains saved even when the lamp is switched off.
Main switch
The touch wheels are used for setting and selecting the colours. When the touch wheel is
F2
Touch wheel
touched, the current program is interrupted and the corresponding colour is displayed.
F3
Brightness
This adjusts the brightness of both the static and the colour sequence programs.
This adjusts the speed of the colour sequence program:
Speed
S-/S+ buttons
F4
Program selection
Select one of the programs for the colour sequences (1 – 9): M button
POWER ON/OFF
Individual zones and lamps can be selected using this zone controller function. A long
F5
(On/off)
press of the POWER ON button (F5) starts the lamp with the white light.
Zone controller
Colour sequence programs
Press the "M" button to select a colour sequence program. You can select the appropriate program
(programs 1 – 9) by clicking repeatedly on this button. Press and hold the POWER ON button (F1 or
F5) for unchanging white light.
No. Colour sequence program
1
Smooth-flowing colour changes: yellow-green-blue-purple-red
2
Pulsating white light
3
Red-green-blue-white: pulsating colour changes
4
Changing colours: red-green-blue-yellow-purple-turquoise-white
5
Flashing colour change: green-blue-white
6
Pulsating red, then three flashes of red
7
Pulsating green, then three flashes of green
8
Pulsating blue, then three flashes of blue
9
Combination of pulsating and flashing colour changes (programs 1 – 8)
Remote control for the warm-white LED (Figure G)
Button
Function
POWER ON
This is the on/off switch for all zones. The most recent settings remain saved even when
G1
(On/off)
the lamp is switched off.
Main switch
Using the rotary wheel, you can adjust for 11 back-light brightness sequences. To make a
Rotary wheel
global adjustment (if you are controlling multiple lamps), press the POWER ON button (G1).
G2
Brightness
To set the brightness for individual zones, first press the desired POWER ON button for the
zone control (G3) and then adjust the brightness of the respective zone.
POWER ON
This selects and assigns zones to the lights. Press the POWER ON button (G1) to select
G3
(On/off)
all zones.
Zone controller
12
www.degardo.de
PAIRING THE REMOTE CONTROL WITH THE LAMP
An unlimited number of lamps can be controlled with one remote control. One remote control can be
assigned to a maximum of four zones. To start the pairing (coupling) process, disconnect the lamp
from the power supply and then reconnect it. For lamps that are not yet paired, the LEDs illuminate red
(RGB) or permanently (LED warm white). Otherwise, the previous setting for the lamp is in use. Within
three seconds, press the "POWER ON" button (F5/G3) for each allocated zone. When the LED flashes
repeatedly, this indicates that the lamp and remote control are paired. To disconnect this assigned
pairing, disconnect the lamp's power supply. Then reconnect the power and repeatedly press the
Zone On key that was assigned to the lamp. The lamp will blink to signal that the pairing is no longer
assigned.
WIFI CONTROLLER
The WiFi controller enables you to control the LUNOCS lamps using an iPhone, iPad or iPod Touch
(iOS 5.1 or later), as well as an Android (version 2.2 or later) smart phone or tablet. All functions can be
controlled using the free app. The WiFi controller can be ordered under article number 227779.
CHANGING THE BATTERIES IN THE REMOTE CONTROL
Open the battery compartment by pushing the compartment lid off towards the back. Replace the
batteries as shown in the battery compartment (use two Micro cells, type AAA). Slide the lid back on
from the back until it clicks into place.
GENERAL INSTRUCTIONS
These instructions contain all of the necessary details for correct usage and care of Degardo LUNOCS
products. Please note the instructions and directions in this product information. Please keep these
instructions for future reference.
EC Declaration of Conformity
We, DENIOS AG, Dehmer Straße 66, 32549 Bad Oeynhausen, hereby declare that the design of our
products conform to the following standards:
• "Niederspannungsrichtlinie" (Low Voltage Directive) 2006/95/EC
• EMV directive (Electromagnetic Compatibility): 2004/108/EG
•
This declaration is invalidated in the event of incorrect use or product modifications which were not
agreed with the manufacturer.
Bad Oeynhausen, dated 04.05.2015
Helmut Dennig (CEO DENIOS AG)
LUNOCS
LUNOCS
www.degardo.de
13
