LCD DESCRIPTION

1. Single measurement result
2. Continuous, surface area and
volume measurement result
3. Mode symbol
4. Reference point

OPERATION

Single measurement
1. Press the turn on/laser button.
2. Press the mode button until mode icon disappears.
3. Press the turn on/laser button.
4. Point the laser at measured direction and press the
measurement button. The result will appear on the display.
Continuous measurement
1. Press the turn on/laser button.
2. Press the mode button, until mode icon disappears.
3. Press and hold the measurement button.
4. Measurement will continue until releasing the button.
Section measurement
1. Press the turn on/laser button.
2. Press the mode button, until section measurement icon
appears.
3. Turn on the laser and point at the measured direction.
4. Press the measurement button. The result will appear on
the display.
5. Every next measurement will be added up. Added up result
will be shown on the bottom of the display.
