--- STROLLER ASSEMBLY ---
STEP 1 Unfolding Stroller
Unfolding stroller for assembly.
1
Place Stroller Frame Assembly (A) on a
clean floor with handle tube and seats
on top.
Unbuckle retaining strap by turning
square plastic loop 90 degrees (1) and
passing it through the plastic "D" ring
(2).
2
See Figure 1.
Pull back on handle to unfold
Stroller Frame Assembly (A). Once
stroller is unfolded press down on
handle until the red Fold Lock Release
(1, 2) on both sides of the handle clicks
into place.
Check to make sure Stroller Frame
Assembly is secure and does not return
to folded position.
AB20076_G10A
Figure 1
See Figure 2.
1
A
2
AB20076_G3A
Figure 2
