Front and Center Seat Back Recline Adjustment
Front and Center Seat recline
adjustment.
The seats have 2 positions upright and
reclined.
To adjust seat back pull up on recline
handle until seat is released. Place
seat into desired position and release
handle. Make sure seat is secured in
position after releasing handle. Check
harness for security after adjusting
seat position.
See Figure 15.
Note: seat must be in upright position to
fold stroller
Rear Seat recline adjustment.
The rear seat has 2 positions upright
and reclined.
To recline seat back, hold seat in
upright position and press on buckle
tabs to release both buckles (1).
Lower seat back into position.
To raise seat into upright position raise
seat back and attach both buckles (1)
together. Check that buckles are fully
engaged before releasing seat back.
See Figure 16.
Note: seat must be in upright position to
fold stroller
Rear Seat Back Recline Adjustment
11
Figure 15
1
Figure 16
AB20076_G18A
1
AB20076_G17A
