Instruction manual
Solar pond pump set
„Tamaro"
These instructions relate ONLY to this product and contain important infor-
mation for using the product for the first time. Please keep these instructions
for later reference and should always accompany the product in the event of
transference to a new user.
1. Introduction
Dear Costumer, thank you for purchasing the solar pump kit.
With this solar pump kit you purchased a product manufactured according to the cur-
rent state of technology.
This product fulfils all requirements of the valid European and
national regulations. The conformity was proved. The relevant
declarations and documentation are deposited with the manu-
facturer.
To maintain this state and guarantee a safe operation, you as the user will have to follow
this operating manual!
2. Safety Instructions
- In case of damages caused by not following
!
this operating manual, the warranty rights
will expire! We exclude liability for any
consequential damages!
- We exclude liability for property or
personal damages caused by inappropriate
handling or not following the safety instructions.
- In these cases any guarantee rights will expire.
Due to safety and admission reasons (CE) it is not allowed to arbitrarily reconstruct and/
or change the solar pump kit.
Therefore, please keep to the operating manual.
The accident prevention rules of the association of the industrial trade cooperative
association for electric plants and working material are to be considered in industrial
environments.
3. Appropriate Use
-
The pumping system is designed for the outdoor use in garden ponds.
-
Direct solar radiation is required for the correct function.
-
The pumping system is characterized by its easy assembly. Tools are not required for
the assembly.
-
The pump must not be used for the raising of drinking water.
-
The performance may be adjusted via a controller on the pump.
-
In order to avoid any disturbing lapping, simply telescope the telescopic ascending
pipe at little.
-
In order to safely interrupt the pumping it is required to interrupt the cable connec-
tion between solar module and pump.
4. Assembly and Initiation
The pumping system consists of the following parts:
1 piece solar module, 1 piece submerged pump in the plastic housing with a 5 m
connecting cable, 4 pipes and different water nozzles.
1. Completely unroll the connecting cable on the pump.
2. Attach the pipes onto the pump and then attach one of the desired sprinklers onto
the ascending pipe.
3. Put the pump in the pond on some stones. Avoid a location directly on the ground
of the pond because a lot of dirt is here sucked in by the pump which will then be
polluted very fast.
4. Now connect the plug of the pump with the socket of the solar module and screw
the cap.
Position the solar module in a sunny, shadow-free place facing south.
Note: The plug is reverse-protected. Do not apply force when inserting the plug. The
glass of the solar modules is sensitive to breakage.
Attention: Risk of injury! A broken module may not be repaired and has to be disposed
of environmentally sound.
Note: For further assembly instructions, please see the instruction of the water pump.
GB
5. Service and Maintenance
In order to preserve the performance of the pump, it is required to wash out the pump
and its parts with warm water depending on the pollution of the water.
For directions for the service and maintenance of the pump storage, please see the
instruction of the pump storage.
Occasionally wipe the solar module clean with a soft and slightly moistened cloth.
Note: Before carrying out operations on the pump, interrupt the plug connection bet-
ween pump and solar module in order to avoid any unintentional starting during the
operations.
6. Technical Data
Solar pumping system
- System voltage:
Solar module
- Nominal power:
- Nominal voltage:
- Nominal current:
- Open-circuit voltage:
- Short-circuit current:
- Projection system:
- Protection class:
- Temperature range:
- Dimensions:
Water pump:
- Operating voltage:
- Max. delivery height:
- Delivery rate:
- Protection system:
- Protection class:
- Temperature range:
Note: Protect the pump from frost!
In cold winter months, it is required to take the pump out of the water and store it in a
warm place. The solar module may be left outside during the winter.
7. Safety Instructions:
DANGER for children! Keep children away from swallowable small parts (ascending
pipe and sprinklers) and the packaging material. Danger of suffocation!
WARNING: risk of stumbling! Lay the connecting cable so that it will not become a
trip hazard!
CAUTION Material damage! When setting up the solar module without module bra-
cket, please pay attention to an adequate stability. The solar module may be damaged
in case of tipping or in case of an impact of a foreign object.
Disposal instruction for electric appliances:
Dear customer, if you want to get rid of the article,
ding to the current regulations. The municipal authority will provide you with
information.
Copyright, www.colibriproducts.ch
Tamaro
17 VDC
10 Wp
17,5 V
580 mA
21,6 V
680 mA
IP 65
III
-30°C to +75°C
400x255x25 mm
17 V DC
ap. 1,3 m
ap. 600 l/h
IP 68
III
+4 to +40°C
please dispose it accor-
