ENGLISH
Before using your product, read all safety instructions. For full instructions
please refer to the user guide available to download from the website
sharpconsumer.eu.
Getting started - initial set up
1.
Use the inputs on the rear panel of the soundbar to connect external
audio and video devices equipped with the corresponding outputs.
Caution! Turn all devices off and disconnect them from the power supply
before starting any connection.
2.
Connect the mains cable to the AC~ Socket of the main unit and then
into a mains socket.
3.
Connect the mains cable to the AC~ Socket of the Subwoofer and
then into a mains socket.
4.
Insert the batteries supplied into the Remote control.
Press the
button on the remote control to switch the main unit ON
or OFF.
5.
Press the
button repeatedly on the unit or press the
the remote control to select the desired mode.
1 Main Unit
1.
Display Window – Show the current status.
2.
Remote Control Sensor – Receive signal from the remote control.
3.
Wall bracket screws
4.
(ON/OFF) button – Switch the unit between ON and Standby mode.
5.
(SOURCE) button – Select the play function.
6.
– Play/pause/resume playback in Bluetooth/USB mode.
Press and hold to activate the pairing function in Bluetooth mode or
disconnect the existing paired Bluetooth device.
7.
VOL+/VOL- buttons – Increase/decrease the volume level.
8.
AC~ Socket
9.
COAXIAL Socket
10. OPTICAL Socket
11. USB Socket – Insert the USB device to play music.
12. AUX Socket – Connect to an external audio device.
13. HDMI (1/2/ARC) Sockets – Connect to a TV via HDMI cable.
2 Wireless Subwoofer
1.
AC~ Socket – Connect to power.
2.
PAIR button – Press activate the pairing function between the main
unit and the subwoofer.
3.
PAIR Indicator – Light up solidly when the pairing succeed.
3 Remote Control
1.
– Switch the unit between ON and STANDBY mode.
2.
– Select the Bluetooth mode.
Press and hold to activate the pairing function in Bluetooth mode or
disconnect the existing paired Bluetooth device.
3.
– Select the play function.
4.
SURR – Turn the surround ON/OFF.
5.
HDMI – Select the HDMI 1/2/ARC mode.
6.
VOL +/- – Increase/decrease the volume level.
7.
/
– Skip to previous/next track in Bluetooth/USB mode.
8.
– Play/pause/resume playback in Bluetooth/USB mode.
9.
– (MUTE) Mute or resume the sound.
10. BASS +/- – Adjust bass level.
11. TRE +/- – Adjust treble level.
12. EQ – Select a preset sound mode.
For using Dolby Atmos®
Dolby Atmos® is available only in HDMI mode.
1. To use Dolby Atmos® in HDMI 1 / HDMI 2 / HDMI ARC mode, your TV has
to support Dolby Atmos®.
2. Make sure that "No Encoding" is selected for bitstream in the audio
output of the connected external device (e.g. Blu-ray DVD player, TV
etc.).
3. While entering Dolby Atmos / Dolby Digital / PCM format, the soundbar
will show DOLBY ATMOS / DOLBY AUDIO / PCM AUDIO.
4. While the soundbar is using Dolby Atmos audio, you can only adjust
the bass level of the subwoofer.
Pairing the Wireless Subwoofer with the Main Unit
Automatic pairing
The subwoofer and soundbar will automatically pair when both units are
plugged into the mains sockets and turned on. No cable is needed for
connecting the two units.
• When the subwoofer is pairing with the main unit, the Pair Indicator will
flash fast.
• When the subwoofer is paired with the main unit, the Pair Indicator will
light up.
NOTE:
ū Do not press the Pair button on the rear of the subwoofer, except for
manual pairing.
ū If the automatic pairing fails, pair the subwoofer with the main unit
manually.
Manual pairing
button on
1. Ensure that all the cables are well connected and the main unit is in
Standby mode.
2. Press and hold the Pair button on the rear of the subwoofer for a
few seconds. The subwoofer will enter the pairing mode and the Pair
Indicator will blink quickly.
3. Press
the button on the main unit or on the remote control to switch
the main unit on.
4. After the wireless connection succeeded, the Pair Indicator will light up.
5. If the Pair indicator blinks, the wireless connection has failed. Unplug
the cable of the subwoofer and then reconnect the main cable after 4
minutes. Repeat step 1 ~ 4.
Bluetooth Operation
Pair Bluetooth-enabled Devices
The first time you connect your bluetooth device to this player, you need to
pair your device to this player.
1. During ON mode, press the
button on the remote control to select Bluetooth mode. "NO BT" will
show on the display if the unit is not paired to any Bluetooth device.
2. Activate your Bluetooth device and select the search mode. "HT-
SBW460" will appear on your Bluetooth device list.
ū If you cannot find the unit, press and hold the button on the remote
control or
"PAIR" and you will hear "Pairing" from the unit.
3. Select "HT-SBW460" in the pairing list. After successful pairing, you will
hear "Paired" from the unit, and the display panel shows "BT".
4. Play music from the connected Bluetooth device.
USB Operation
1. Insert the USB device.
2. Press the
the remote control to select USB mode.
3. During playback:
ū To pause or resume play, press the
on the unit.
ū To skip to the previous/next file, press the
remote control.
DEUTSCH
Lesen Sie sich vor der Verwendung des Produkts alle Sicherheitshinweise durch.
Vollständige Instruktionen finden Sie im Benutzerhandbuch, dass Sie sich auf
unserer Webseite sharpconsumer.eu herunterladen können.
button repeatedly on the unit or the
button on the unit to be searchable. The display will show
button repeatedly on the unit or press the
button on the remote control or
1
button on
/
buttons on the
