ENGLISH
Before using your product, read all safety instructions. For full instructions
please refer to the user guide available to download from the website sharp.
eu/av.
Getting started - initial set up
1. Use the inputs on the rear panel of the soundbar to connect external
audio and video devices equipped with the corresponding outputs
(Pic. 1).
Caution! Turn all devices off and disconnect them from the power supply
before starting any connection.
2. Connect the power adapter to the DC Socket of the unit and then into
a mains socket.
3. Insert the batteries supplied into the Remote control.
Press the button on the remote control to switch the main unit ON
or OFF.
4. Press the button repeatedly on the unit or press the
the remote control to select the desired mode.
NOTE: In Optical In mode, Coaxial In mode, ARC mode or HDMI
mode, the source has to be set to PCM audio output
1 Panels& Controls
1. Source LED
2. Power LED
3. IR sensor
4. VOL+
5. VOL-
6. Source
7. Pair
8. Power On / Off
9. HDMI Input
10. HDMI Output
11. COAX IN
12. AUX IN
13. Optical IN
14. DC IN
15. Firmware update port
2 The function of keys:
1. Power ON/OFF: Press the button to power ON/OFF the soundbar
2. Vol+: Increase the volume
3. Vol-:Decrease the volume
4. Source: Switches the sound source
5. Pair:
State
Wi-Fi mode
Bluetooth connected
Standby
button on
Long press
Connect the slave speaker to
main speaker
Disconnect Bluetooth
Close Wi-Fi hotspot
Indication Lights:
Source LED
Mode
Wi-Fi Disconnected
Connected
Pairing
Bluetooth Disconnected
Connected
AUX IN
Optical IN
Coaxial IN
HDMI IN
ARC
Power LED
Status
Power ON
Power OFF
Power ON & MUTE
3 Remote control
1. POWER: ON/OFF the soundbar
2. MUTE: Silences the soundbar
3. VOL+: Increase the volume
4. VOL-: Decrease the volume
5. PREVIOUS: Switches to the previous song when the soundbar is
connected to your device through Bluetooth or Wi-Fi connection
6. NEXT: Switches to the next song when the soundbar is connected to
your device through Bluetooth or Wi-Fi connection
7. PLAY/PAUSE: Plays or pauses a song when the soundbar is connected
to your device through Bluetooth or Wi-Fi connection
8. SOURCE: Changes the input of the soundbar
9. EQUALISER: Switch diff erent preset equaliser settings for the speaker
10. PAIR:
State
Wi-Fi mode
Bluetooth connected
Standby
11. BASS-: Decrease the bass eff ect of the soundbar
12. BASS+: Increase the bass eff ect of the soundbar
Music Playing
Wi-Fi mode:
1. You can use app to search for your HT-SBW420 and then add it to
the management list. It is then possible to play back music form your
connected device. If you would like the same music to play from two
speakers at the same time (Multi room mode), follow the guidance in
the app.
1
LED Light Indication
Flash Green
Solid Green
Quick Flash Green
Flash Blue
Solid Blue
Solid Purple
Solid Cyan
Solid Yellow
Solid Red
Solid White
LED Light Indication
White
Red
Flash Red
Long press
Connect the slave speaker to
main speaker
Disconnect Bluetooth
Close Wi-Fi hotspot
