BMW R1200GS Bauanleitung

PORTAVALIGIE LATERALE SPECIFICO - SPECIFIC TUBULAR SIDE-CASE HOLDER
PORTE-VALISES LATÉRAUX SPÉCIFIQUE - SPEZIFISCHES STAHLROHR-SEITENTRAEGER
PORTA MALETAS LATERALES ESPECÍFICO
BMW R1200GS
2006-2009
ISTRUZIONI DI MONTAGGIO - MOUNTING INSTRUCTIONS
INSTRUCTIONS DE MONTAGE - BAUANLEITUNG - INSTRUCCIONES DE MONTAJE
7
8
GL1626
VITE TSCEI M6x20mm VITE TEF M6x90mm
PIASTRINA
SCREW SCREW
LITTLE PLATE VIS VIS
PETITE PLAQUE SCHRAUBE
SCHRAUBE
PLAETTCHEN TORNILLO TORNILLO
PLAQUETA
Q.TY n.2
Q.TY n.4
(Dx-Sx)
B
SUPPORTO
SUPPORT
SUPPORT
HALTERUNG
SOPORTE
Q.TY n.2
9 10
VITE TBEI M6x40mm VITE TBEI M8x40mm
SCREW SCREW
VIS0 VIS
SCHRAUBE SCHRAUBE
TORNILLO TORNILLO
Q.TY n.4 Q.TY n.2 Q.TY n.2
A
C
D
1 2
PONTE POSTERIORE PIASTRINA
REAR BRIDGE LITTLE PLATE
PONT POSTERIEURE PETITE PLAQUE
VERBINDUNGSROHR PLAETTCHEN
PUENTE TRASERO PLAQUETA
Q.TY n.2
Q.TY n.1
(Dx-Sx)
11
A
14
B
3 4 5
GL1630
GL1633 GL1627
GL1635
PIASTRINA PIASTRINA
LITTLE PLATE LITTLE PLATE
PETITE PLAQUE PETITE PLAQUE
PLAETTCHEN
PLAETTCHEN
PLAQUETA PLAQUETA
Q.TY n.2 Q.TY n.2
(Dx-Sx)
10
13
7
3
4
© Copyright 020410AR-Rev00, 1/3
6
+
GL1634
PIASTRINA
LITTLE PLATE
PETITE PLAQUE
PLAETTCHEN
PLAQUETA
Q.TY n.2
(Dx-Sx)
11
12
6
8
