INSTRUCTION MANUAL
Thank you for purchasing the LED PAR-64. Every LED PAR-64 has been
well tested and has been shipped in perfect operating condition.
Introduction
The LED PAR-64 IBIZA Light is part of a wider range of LED PAR CANS. This
LED PAR-64 is compact and light weight and very easy to use. The unit can
run in stand alone mode.
Safety Recommendations
•
Do not attempt any repairs yourself! Doing so will void your manufactures
warranty. In the unlikely event your unit may require service please
contact us.
•
To prevent or reduce the risk of electrical shock or fire, do not expose this
unit to rain or any moisture.
•
Please read this user manual carefully to familiarize yourself with the
basic operations of this unit.
•
Before plugging to power be sure the local power outlet matches with the
required voltage of the unit
•
Do not remove the cover under any circumstances in case you're not
qualified to do so.
•
Never connect to power when cover is removed.
•
Never use this unit if it becomes damaged.
•
Never connect this unit to any kind of dimmer- and/or power-pack.
•
If the unit will not be used for a long time, disconnect it from power supply.
•
Always mount this unit safe and stable, and make sure the area will have
proper ventilation.
•
Take care this unit will not mounted in areas close to heat sources such
as lighting fixtures, amplifiers, heat registers, stoves and radiators.
©Copyright Lotronic 2011
A
N
F
O
R
D
J
-
L
I
G
H
T
1
0
A
N
F
O
R
D
J
-
L
I
G
H
T
1
0
General instructions
Before plugging this unit to power make sure the voltage in your area matches
the required voltage for the LED PAR-64. All PAR-LED units can be powered
by 90/260V and 50/60Hz.
0
0
There are 2 ways to control your LED PAR-64. The first option is by 'stand
alone' function and the second one is fixed operation.
Menu Control Panel
A512: No function
CCCC:
C1: green
C2: red
C3: blue
C4: yellow
C5: light blue
C6: Violet
C7: white
AUTO: Automatic colour change and
reaction to the music
Srun: Colour change to the rhythm of the music
Specifications
Operating modes: Auto, Sound activated, fixed
Functions: Color changer (fast or slow)
Lamp: 181 x 10mm hi bright LEDs
Life time of the lamps:80-100.000 operating hours
Colors:16.7 millions
Consumption:18W
Power supply: 90V-250Vac/50-60Hz
IMPORTANT NOTE: Electric products must not be put into household
waste. Please bring them to a recycling centre. Ask your local
authorities or your dealer about the way to proceed
