SAfETy INSTRUCTIONS
Read this instruction manual and keep it for future reference.
• Improper, unstable installation may result in damage or injury. Producer does not claim liability for any
damages/injuries caused by inappropriate installation and handling. Use only for the purpose intended as
indicated in this user's manual.
• Before use, check whether the product and its parts are not damaged in any way. Do not use this device if
it's damaged.
• Use only authorized accessories.
• Avoid placing the antenna in direct vicinity of devices and constructions which may cause interference,
e.g. other devices for wireless connectivity.
• Safety gear and proper tools must be used during installation. This product should be installed by qualified
professional with proper mechanical skills and acknowledged with this instruction manual.
• All cables of the device should be routed so that they are secured from being pinched or squeezed.
• Keep away from children, this product is not a toy.
• Antena for outdoor use. Amplifier and power adapter of the active antenna are for indoor use - protect them
from water and humidity.
• In case of active antenna, use antenna cable to connect amplifier to antenna; later plug amplifier to power
adapter. Next, connect amplifier to TV receiver with antenna cable. Connect the power adapter to power
supply socket.
• Do not disassemble / repair / modify this device yourself. In case of damage, contact authorized service point
for check-up or repair. Any modifications implemented by user in the product pose risk of injury or damage
and void warranty!
TECHNICAL DATA
Frequency Range
Channels
Impedance
No.of elements
Front-back ratio
Beam width H / V
Polarisation
Antenna length
LTE filter
Set includes
waterproof cap, F connector
External amplifier
Gain
Noise Figure
Power adaptor
Producer reserves rights to change product overview, specifications and manual instruction without prior notice. Please note: above
illustrations and descriptions are for reference only!
English
Correct Disposal of This Product
(Waste Electrical & Electronic Equipment)
(Applicable in the European Union and other European countries with separate collection systems) This marking shown on the
product or its literature, indicates that it should not be disposed with other household wastes at the end of its working life. To prevent
possible harm to the environment or human health from uncontrolled waste disposal, please separate this from other types of
wastes and recycle it responsibly to promote the sustainable reuse of material resources. Household users should contact either
the retailer where they purchased this product, or their local government office, for details of where and how they can take this item
for environmentally safe recycling. Business users should contact their supplier and check the terms and conditions of the purchase
contract. This product should not be mixed with other commercial wastes for disposal.
Made in China for LECHPOL ELECTRONICS Sp. z o.o. Sp.k., ul. Garwolińska 1, 08-400 Miętne.
Owner's manual
ANT0640
(VHF) 174-230 MHz / (UHF) 470-790 MHz
-
-
-
-
Input voltage: 100-230 V AC | Output voltage: 5 V DC / 550 mA
ANT0641
5-12; 21-60
75 Ohm
28
25 dB
H38° / V80°
horizontal
105,5 cm
yes
waterproof cap, F connector, amplifier, power adaptor
yes
20 dB
< 3,5 dB
Output power: 2,75 W
Average active efficiency: 72.1%
No-load power consumption: 0,06 W
EN
9
