VESA Cynap Pure Montage

VESA ™ Mount (MIS-D 75mm / 100
The Cynap Core is designed to be mounted onto a standard VESA™ mount
To mount the Cynap Core onto a mount (or monitor back side), the interface plate needs to be fixed securely onto the mount in the right
orientation (note "THIS WAY UP").
Alternatively, the interface plate can also be used to mount Cynap Core onto a wall or similar. Select fitting screws and anchors, when
needed, to mount the plate securely.
Place Cynap Core onto the interface plate until the fixing lug snaps into the slot and establish your cable connections.
To remove Cynap Core from the mount, disconnect all cables and simply pull the lug to lift the device.
100
THIS WAY UP
171.5
VESA™ Mount or Monitor backside
T H
I S
W
A Y
U P
mount
mm C - according VESA FDMI™)
75
Use the holes to suit
your mount or monitor.
□
75mm /
□
( 75mm /
Please note:
Consider heat output of 90 Watt!
Keep side area clear for fresh air ventilation.
Keep area at the back of Cynap Core clear for cable connections.
Metal cabinets will decrease the possible range of wireless devices!
To select the screws, note the max. useable depth of thread.
Select the anchors and screws depending on wall surface.
1.5
9.8
Wall Mount
□
100mm
T H
I S
W
A Y
U P
Printed in Austria - December 2017
□
100mm) .
part no. description
113906 VESA Mount Plate
- Screw
- Anchor when needed
T H
I S
W
A Y
U P
remove
qty.
1
4
4
T H
I S
W
A Y
U P
