Motherboard Layout
24.4cm (9.6 in)
USB 3.0
T: USB1
B: USB2
USB 3.0
T: USB3
B: USB4
USB 3.0
Top:
T: USB5
RJ-45
B: USB6
USB 2.0
T: USB0
B: USB1
USB 3.0
Top:
T: USB7
RJ-45
B: USB8
44
43
42
41
LAN
PHY
40
39
38
37
AUDIO
CODEC
36
HDMI_SPDIF1
1
HD_AUDIO1
35
34
1
ATX 12V Power Connector (ATX12V1)
2
1155-Pin CPU Socket
3
Power Fan Connector (PWR_FAN1)
4
CPU Fan Connector (CPU_FAN1)
5
CPU Fan Connector (CPU_FAN2)
6
2 x 240-pin DDR3 DIMM Slots
(DDR3_A1, DDR3_B1, Black)
7
2 x 240-pin DDR3 DIMM Slots
(DDR3_A2, DDR3_B2, Black)
8
ATX Power Connector (ATXPWR1)
9
USB 3.0 Header (USB3_11_12, Black)
10
USB 3.0 Header (USB3_9_10, Black)
11
Intel Z77 Chipset
12
SATA3 Connectors (SATA3_A1_A2, Gray)
13
SATA3 Connectors (SATA3_A3_A4, Gray)
14
SATA3 Connectors (SATA3_0_1, Gray)
15
SATA2 Connectors (SATA2_2_3, Black)
16
SATA2 Connectors (SATA2_4_5, Black)
17
Reset Switch (RSTBTN)
18
Power Switch (PWRBTN)
19
Power LED Header (PLED1)
20
System Panel Header (PANEL1, Black)
21
Chassis Speaker Header (SPEAKER1, Black)
22
Clear CMOS Jumper (CLRCMOS1)
23
SPI Flash Memory (64Mb)
2
manuals search engine
1
2
3
4
5
6
7
PWR_FAN1
CPU_FAN2
ATX12V1
CPU_FAN1
LAN
PHY
CHA_FAN3
SLI/XFIRE_PWR1
DDR3 3000+
USB3_11_12
PCIE1
X
X
Fast USB
Fast LAN
PCIE2
PCIE3
X
2 oz Copper PCB
Fast RAM
PCIE4
Z77 WS
Intel
PCIE5
Z77
CMOS
PCIE6
Battery
RoHS
PCIE7
IR1
1
USB6_7
Dr.
CLRCMOS1
COM1
PLED1
FRONT_1394
CHA_FAN1
USB4_5
USB2_3
1
1
PLED PWRBTN
CHA_FAN2
Debug
64Mb
1
SPEAKER1
BIOS
1
1
1
1
1
1
1
HDLED RESET
PANEL1
CIR1
33
32
31
30
29
28
27
26
25
24
23
22
21
24
Dr. Debug
25
USB 2.0 Header (USB2_3, Black)
26
USB 2.0 Header (USB4_5, Black)
27
USB 2.0 Header (USB6_7, Black)
28
Consumer Infrared Module Header
(CIR1, Gray)
29
Chassis Fan Connector (CHA_FAN2)
30
Chassis Fan Connector (CHA_FAN1)
31
Front Panel IEEE 1394 Header
(FRONT_1394, Black)
32
Infrared Module Header (IR1)
33
COM Port Header (COM1)
34
HDMI_SPDIF Header
(HDMI_SPDIF1, Black)
35
Front Panel Audio Header
(HD_AUDIO1, Black)
36
PCI Express 3.0 x16 Slot (PCIE7, Black)
37
PCI Express 2.0 x1 Slot (PCIE6, Black)
38
PCI Express 3.0 x16 Slot (PCIE5, Black)
39
PCI Express 2.0 x16 Slot (PCIE4, Black)
40
PCI Express 3.0 x16 Slot (PCIE3, Black)
41
PCI Express 3.0 x16 Slot (PCIE2, Black)
42
PCI Express 3.0 x16 Slot (PCIE1, Black)
43
SLI / XFIRE Power Connector
44
Chassis Fan Connector (CHA_FAN3)
ASRock Z77 WS Motherboard
8
9
10
USB3_9_10
11
12
13
14
15
16
17
RSTBTN
18
PWRBTN
19
20
