CITROËN/FIAT/PEUGEOT
• Relay
Pickup & Chassis cab
• Ducato Pickup & Chassis cab
• Boxer
Pickup & Chassis cab
06/06
06/06
06/06
brink.eu
1/9
Werbung
Verwandte Anleitungen für Brink 709347
Inhaltszusammenfassung für Brink 709347
- Seite 1 Wiringkit Einbauanleitung 709347 19500520 Installation instructions Consignes de montage CITROËN/FIAT/PEUGEOT Montagehandleiding Montagevejledning • Relay Pickup & Chassis cab 06/06 Monteringsinstruksjon • Ducato Pickup & Chassis cab 06/06 Installationsanvising • Boxer Pickup & Chassis cab 06/06 Asennusohje Intruzioni per il montaggio Instrucciones de montaje Instuções de montagem...
- Seite 2 Installation of the towing electrics kit must be undertaken by In case of missing a rear fog lamp on the trailer, it should be retrofitted. za specialist workshop or an appropriately qualified person. We accept no responsibility and give no guarantee for technical and electrical Before starting work, you must read the installation instruc- modifications made after the initial operation of the towing electrics kit by the tions through completely.
-
Seite 3: Symbol Explanation
SYMBOL EXPLANATION left (58-L) respectively cigarette lighter / right (58-R) tail light accessory socket stop light (54) / loudspeaker / buzzer high mounted, third stop light (54) turn signal indicator left Park Distance Control switch / sour c e of function turn signal indicator right rear fog light(s) Connect together... - Seite 4 40 mm 87500860 / 09.05.2019 / Subject to changes...
- Seite 5 Svart Black Schwarz Negro Noir Nero Preto Zwart Sort Svart Musta Cerná Fekete Czarny Rojo Rouge Rosso Vermelho Rood Rød Rød Röd Punainen Cervená Piros Czerwony Green Grün Verde Vert Verde Verde Groen Grøn Grønt Grön Vihreä Zelená Zöld Zielony Pomaran- Orange Orange...
- Seite 6 Option 1 Option 2 B+/30 87500860 / 09.05.2019 / Subject to changes...
- Seite 7 OPTIONAL BL/YL BL/YL everse BL/YL BL/YL Supplementary harness 38400501 SETUP Ignition ON 87500860 / 09.05.2019 / Subject to changes...
- Seite 8 everse SETUP Ignition ON OPTIONAL Optional: Adapter socket 768019 Trailer 7-pin 13-pin Simulator for 7- and 13-pin Sockets Part-no. 765069 87500860 / 09.05.2019 / Subject to changes...
- Seite 9 Diagnosis function of control LEDs SETUP Ignition ON B+/30: PIN 1 + PIN 14 B+/30 < 10,8 V B+/30: PIN 1 or PIN 14 /31: PIN 21 2x B+/30: PIN 1 + PIN 14 Lamp substitution if the trailer indicators fail If the indicator is activated, the corresponding rear lamp on the trailer becomes the indicator lamp substitution): If an indicator fails the left or right rear light compensates the faulty indicator by flashing at the...
