GB
Cleaning, maintenance and ordering of spare
parts
Always pull out the mains power plug before
starting any cleaning work.
Cleaning
Keep all safety devices, air vents and the motor
housing free of dirt and dust as far as possible.
Wipe the equipment with a clean cloth or blow it
with compressed air at low pressure.
We recommend that you clean the device
immediately each time you have finished using it.
Clean the equipment regularly with a moist cloth
and some soft soap. Do not use cleaning agents
or solvents; these could attack the plastic parts of
the equipment. Ensure that no water can seep
into the device.
Carbon brushes
In case of excessive sparking, have the carbon
brushes checked only by a qualified electrician.
Important! The carbon brushes should not be
replaced by anyone but a qualified electrician.
Replacing the drive belt
Loosen the screw and take off the belt guard.
Remove the worn drive belt and clean both belt
discs.
Place the new drive belt on the small belt disc
and, while turning the knife block, pull the belt
over the large belt disc too.
Make sure the longitudinal grooves on the drive
belt are inside the guide grooves of the drive
wheels.
Remount the belt guard and screw it firmly in
place.
Maintenance
There are no parts inside the equipment which
require additional maintenance.
Ordering of replacement parts
Please quote the following data when ordering
replacement parts:
Type of machine
Article number of the machine
Identification number of the machine
Replacement part number of the part required
For our latest prices and information please go to
www.isc-gmbh.info
10
13.12.2007 9:15 Uhr Seite 10

TECHNICAL DATA

Power supply
Rating
Idling speed n tr
Planing depth
Planing width
Rebate depth
Weight
Earthing
Sound and vibration
Sound and vibration values were measured in
accordance with EN 60745.
L sound pressure level
pA
L sound power level
WA
Wear ear-muffs.
The impact of noise can cause damage to hearing.
Total vibration values determined in accordance with
EN 60745.
Vibration emission value a = 3,61 m/s
h
Important!
The vibration value changes according to the area of
application of the electric tool and may exceed the
specified value in exceptional circumstances.
230 V - 50 Hz
900 W
16,000 rpm
0-3 mm
82 mm
0-15 mm
3 kg
II/®
87,6 dB(A)
98,6 dB(A)
2
