Siemens SIRIUS 3RW5 Gerätehandbuch Seite 147

Angezeigter Name und Ebene
1. 2. 3. 4. Ebene
Phase current I L3 max (%)
Phase current I L3 max (rms)
Phase current I L3 min (%)
Phase current I L3 min (rms)
Starting current I L1 max (rms)
Starting current I L2 max (rms)
Starting current I L3 max (rms)
Starting current I max (rms)
Measured values
Active power
Asymmetry
Line frequency
Line voltage U L1-L2 (rms)
Line voltage U L2-L3 (rms)
Line voltage U L3-L1 (rms)
Motor temperature rise
Output frequency
Phase current average (%)
Phase current average (rms)
Phase current I L1 (%)
Phase current I L1 (rms)
Phase current I L2 (%)
Phase current I L2 (rms)
PROFINET Kommunikationsmodule SIRIUS 3RW5
Gerätehandbuch, 06/2020, A5E35631297001A/RS-AC/003
Variable
Browse-Name
Phase_current_I_L3_max_
percent_MAXP
Phase_current_I_L3_max_rms_
MAXP
Phase_current_I_L3_min_
percent_MAXP
Phase_current_I_L3_min_rms_
MAXP
Starting_current_I_L1_max_rms_
MAXP
Starting_current_I_L2_max_rms_
MAXP
Starting_current_I_L3_max_rms_
MAXP
Starting_current_I_max_rms_
MAXP
Measured_values
Active_power_MESW
Asymmetry_MESW
Line_frequency_MESW
Line_voltage_U_L1_L2_rms_
MESW
Line_voltage_U_L2_L3_rms_
MESW
Line_voltage_U_L3_L1_rms_
MESW
Motor_temperature_rise_MESW
Output_frequency_MESW
Phase_current_average_percent_
MESW
Phase_current_average_rms_
MESW
Phase_current_I_L1_percent_
MESW
Phase_current_I_L1_rms_MESW
Phase_current_I_L2_percent_
MESW
Phase_current_I_L2_rms_MESW
Funktionen
8.4 OPC UA Server
NodeId. Datenformat
Identifier
i =
1074 Float
1075 Float
1076 Float
1077 Float
1078 Float
1079 Float
1080 Float
1081 Float
1022 -
1082 Float
1083 UInt32
1084 Float
1085 Float
1086 Float
1087 Float
1088 UInt32
1089 Float
1090 Float
1091 Float
1092 Float
1093 Float
1094 Float
1095 Float
Einheit
%
A
%
A
A
A
A
A
-
kW
%
Hz
V
V
V
%
Hz
%
A
%
A
%
A
147
