Control Panel Description

BUTTON FUNCTION
<MENU> Exits from the current menu or function
<UP> Navigates upwards through the menu list and increases the numeric value when in a function
<DOWN> Navigates downwards through the menu list and decreases the numeric value when in a function
Enables the currently displayed menu or sets the currently selected value into the selected
<ENTER>
function
Menu Map
Mode
Address
Static Colors
Auto Programs
Auto Speed
Dimmer
Sound Mode
Master/slave
Custom Color
Mixing
Infrared Mode

DMX Linking

The Wash FX Hex can work with a DMX controller. Instructions for connecting and configuring this product for DMX
operation are in the User Manual. If you are not familiar with DMX, download the DMX Primer from www.chauvetdj.com.
Starting Address
To ensure full access to all channels available in each DMX mode, the highest recommended DMX address is 473.
Master/Slave Connection
The Wash FX Hex uses the DMX data connection for its Master/Slave mode. Information about configuring the
Wash FX Hex for Master/Slave operation is in the User Manual, which is available from the Chauvet website.
IRC-6 (Infrared Remote Control)
The Wash FX Hex can be operated with the CHAUVET IRC-6. For more information about the IRC-6, download
instructions for the IRC-6 or the Wash FX Hex User Manual from www.chauvetdj.com.
3
QUICK REFERENCE GUIDE
Programming Levels
3CH
6CH
d001–512
11CH
40CH
C-- C001–063
P--
S-- S001–100
dIM L001–255
SND
SLV
r000–255
g000–255
b000–255
u--
a000–255
w000–255
u000–255
SET
Description
Sets the DMX personality and address
Static colors
P 1–25 Auto programs
Program speed for P 1–25
Adjusts the dimmer on auto and sound
programs
1–9 Sound mode
SLV1 Copies the master unit
SLV2 Mirrors the master unit
Custom static colors
Combines red, green, blue, amber, white,
and UV
on
Turns infrared on or off
off
Wash FX Hex QRG Rev. 1
